Kubota MX5100 - Check Point of Every 600 Hours

G-32
MX5100, WSM
G GENERAL
Greasing Front Wheel Hub (2WD)
1. Detach the cover, and apply bearing grease.
W10358080
Replacing Fuel Filter Element
1. See “Cleaning Fuel Filter Element” in “CHECK POINTS OF
EVERY 100 HOURS”.
2. Replace the fuel filter element (4).
IMPORTANT■
• If dust and dirt enter the fuel system, the fuel pump and the
injection nozzles are subject to premature wear.
W11084790
[7] CHECK POINT OF EVERY 600 HOURS
Adjusting Front Axle Pivot
1. Loosen the lock nut (2), tighten the adjusting screw (1) all the
way, and then tighten the adjusting screw (1) by 1/6 turn.
2. Retighten the lock nut (2).
3. Refer to “6. FRONT AXLE”.
NOTE■
• If the front axle pivot pin adjustment is not correct, front
wheel vibration can occur causing vibration in the steering
wheel.
W11054130
(1) Front Wheel Hub Cover (2WD)
(1) Fuel Filter Cock
(2) Fuel Filter Bowl
(3) O-ring
(4) Filter Element
(5) Spring
(6) Screw Ring
A : Close
(1) Adjusting Screw (2) Lock Nut
