Kubota MX5100 - 2 Servicing Specifications

6-S2
MX5100, WSM
FRONT AXLE
2. SERVICING SPECIFICATIONS
2WD TYPE
W10138740
Item Factory Specification Allowable Limit
Front Wheel Alignment Toe-in 2 to 8 mm
0.079 to 0.315 in.
–
Front Wheel Axial Sway Less than 5.0 mm
0.197 in.
–
Knuckle Shaft to Bushing
Knuckle Shaft
Bushing
Clearance
O.D.
I.D.
0.000 to 0.285 mm
0.00000 to 0.01122 in.
27.880 to 27.900 mm
1.09764 to 1.09842 in.
27.900 to 28.165 mm
1.09842 to 1.10886 in.
0.4 mm
0.016 in.
–
–
Front Axle Middle Boss to Front Axle Shaft
Bracket Bushing
Front Axle Middle Boss
Bushing
Clearance
O.D.
I.D.
0.000 to 0.177 mm
0.00000 to 0.00697 in.
39.938 to 40.000 mm
1.57236 to 1.57480 in.
40.000 to 40.115 mm
1.57480 to 1.57933 in.
0.3 mm
0.012 in.
–
–
