Kubota MX5100 - Page 309

6-S3
MX5100, WSM
FRONT AXLE
4WD TYPE
W10109890
Item Factory Specification Allowable Limit
Front Wheel Alignment Toe-in 2 to 8 mm
0.079 to 0.315 in.
–
Front Wheel Axial Sway Less than 5.0 mm
0.197 in.
–
Differential Case, Differential Case Cover
to Differential Side Gear
Differential Case
Differential Case Cover
Differential Side Gear
Clearance
I.D.
I.D.
O.D.
0.04 to 0.123 mm
0.00157 to 0.00484 in.
32.000 to 32.062 mm
1.25984 to 1.26228 in.
32.000 to 32.062 mm
1.25984 to 1.26228 in.
31.939 to 31.960 mm
1.25744 to 1.25827 in.
0.20 mm
0.0079 in.
–
–
–
Pinion Shaft to Differential Pinion
Pinion Shaft
Differential Pinion
Clearance
O.D.
I.D.
0.064 to 0.100 mm
0.00252 to 0.00394 in.
13.950 to 13.968 mm
0.54921 to 0.54992 in.
14.032 to 14.050 mm
0.55244 to 0.55315 in.
0.25 mm
0.0096 in.
–
–
Differential Pinion to Differential Side Gear Backlash 0.2 to 0.3 mm
0.008 to 0.012 in.
0.4 mm
0.016 in.
Spiral Bevel Pinion Shaft Turning Torque 0.98 to 1.18 N
0.10 to 0.12 kgf
0.72 to 0.87 lbf
–
Spiral Bevel Pinion Shaft to Spiral Bevel
Gear
Backlash 0.2 to 0.3 mm
0.008 to 0.012 in.
–
10T Bevel Gear to 14T Bevel Gear Backlash 0.2 to 0.3 mm
0.008 to 0.012 in.
0.6 mm
0.024 in.
9T Bevel Gear to 43T Bevel Gear Backlash 0.2 to 0.3 mm
0.008 to 0.012 in.
0.6 mm
0.024 in.
