Kubota MX5100 - Check Points of Every 50 Hours

G-21
MX5100, WSM
G GENERAL
[3] CHECK POINTS OF EVERY 50 HOURS
Lubricating Grease Fittings
1. Apply a small amount of multi-purpose grease to the following
positions shown in the figures.
NOTE■
• Apply a small amount of multipurpose grease to the
following points every 50 hours.
If the machine is operated in extremely wet and muddy
conditions, lubricating grease fittings more often.
• When apply a grease to the front axle support, remove the
breather plug and apply a grease until grease overflows
from breather plug. After greasing reinstall the plug.
W10308650
(1) Grease Fitting (Knuckle Shaft RH,
LH)
(2) Grease Fitting (Front Wheel Case
Support RH, LH)
(3) Grease Fitting (Front Axle Support)
(4) Grease Fitting (Top Link)
(5) Grease Fitting (Lifting Rod RH)
(6) Grease Fitting (Top link bracket, if
equipped with draft control)
(7) Battery Terminal
[A] 2WD Type
[B] 4WD Type
