G-67
MX5100, WSM
G GENERAL
[5] IMPLEMENT LIMITATIONS
The KUBOTA Tractor has been thoroughly tested for proper performance with implements sold or approved by
KUBOTA. Use with implements which exceed the maximum specifications listed below, or which are otherwise unfit
for use with the KUBOTA Tractor may result in malfunctions or failures of the tractor, damage to other property and
injury to the operator or others. [Any malfunctions or failures of the tractor resulting from use with improper implements
are not covered by the warranty.]
• Implement size may vary depending on soil operating conditions.
Tread (max. width)
Lower link end max. lifting weight W
0Front
Rear
2WD 4WD
1530 mm (60.2 in.) 1325 mm (52.2 in.) 1490 mm (58.7 in.) 1300 kg (2870 lbs)
Actual figures
Implement weight W
1 and / or size Max. Drawbar Load W2
Trailer loading weight W3 Max.
capacity
As in the following list
(Shown on the next page)
750 kg (1650 lbs) 3500 kg (7700 lbs)
Lower link end max. hydraulic lifting capacity ..... W
0
Implement weight................................................ The implement’s weight which can be put on the lower link : W1
Max. drawbar load .............................................. W2
Trailer loading weight .......................................... The max. loading weight for trailer (without trailer’s weight ) : W3
