G-68
MX5100, WSM
G GENERAL
NOTE■
• Implement size may vary depending on soil operating conditions.
W10127360
No. Implement Remarks MX5100
1Trailer
Max.Load Capacity 3500 kg (7700 lbs)
Max. Drawbar Load 750 kg (1650 lbs)
2Mower
Rotary-Cutter
Max. Cutting Width 2130 mm (84 in.)
Max.Weight 450 kg (1000 lbs)
Flail Mower
Max. Cutting Width 1830 mm (72 in.)
Max.Weight 500 kg (1100 lbs)
Sickle Bar
Max. Cutting Width 2130 mm (84 in.)
Max.Weight 500 kg (1100 lbs)
3 Sprayer Max. Tank Capacity
Rear mounted 500 L (130 U.S.gals)
Pull type 2000 L (529 U.S.gals)
4 Rotary Tiller Max. Tilling Width 1830 mm (72 in.)
5 Bottom Plow Max. size 16 in. × 2
6 Disc-harrow (Pull type)
Max. Harrowing Width 2130 mm (84 in.)
Max. Weight 400 kg (880 lbs)
7 Chisel Plow
Max. Cutting Width 1830 mm (72 in.)
Max. Weight 350 kg (770 lbs)
8 Broad Caster
Max. Tank Capacity 300 L (80 U.S.gals)
Max. Weight 100 kg (220 lbs)
9 Manure Spreader Max. Capacity 2000 kg (4400 lbs)
10 Cultivator
Max. Width 2450 mm (96 in.)
Number of Rows 4
Max. Weight 400 kg (880 lbs)
11 Front Blade
Max. cutting width 1830 mm (72 in.)
Max. oil pressure 17.2 MPa (175 kgf/cm
2
, 2490 psi)
Sub frame Necessary
12 Rear Blade
Max. Cutting Width 1830 mm (72 in.)
Max. Oil Pressure 17.2 MPa (175 kgf/cm
2
, 2490 psi)
13 Front-end Loader
Max. Lifting Capacity 850 kg (1870 lbs)
Max. Oil Pressure 17.2 MPa (175 kgf/cm
2
, 2490 psi)
Sub frame Necessary
14 Box Blade
Max. Cutting Width 1830 mm (72 in.)
Max. Weight 450 kg (1000 lbs)
15 Back Hoe
Max. digging depth 2290 mm (90 in.)
Max. weight 450 kg (990 lbs)
Sub frame Necessary
16 Snow Blade
Max. width 1830 mm (72 in.)
Max. Weight 400 kg (880 lbs)
