5-S2
MX5100, WSM
BRAKES
2. SERVICING SPECIFICATIONS
W10138740
Item Factory Specification Allowable Limit
Brake Pedal Free Travel 15 to 20 mm
5/8 to 13/16 in.
Keep the free travel in
the right and left brake
pedals equal
–
–
Brake Lever Link Shaft to Bushing
Brake Lever Link Shaft
Brake Lever Link Bushing
Clearance
O.D.
I.D.
0.125 to 0.195 mm
0.00492 to 0.00768 in.
19.955 to 19.975 mm
0.78563 to 0.78642 in.
20.100 to 20.150 mm
0.79134 to 0.79331 in.
1.0 mm
0.039 in.
–
–
Cam Plate Flatness – 0.3 mm
0.012 in.
Cam Plate and Ball Height 20.9 to 21.1 mm
0.823 to 0.831 in.
20.5 mm
0.8071 in.
Brake Disc Thickness 4.6 to 4.8 mm
0.181 to 0.189 in.
4.2 mm
0.165 in.
Brake Plate Thickness 2.54 to 2.66 mm
0.1000 to 0.1047 in.
2.1 mm
0.0827 in.
