2-S4
MX5100, WSM
CLUTCH
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts : See page G-10, G-11.)
W10127360
Item N·m kgf·m lbf·ft
Starter’s terminal B mounting nut 7.8 to 9.8 0.8 to 1.0 5.8 to 7.2
Steering wheel mounting nut 48.0 to 55.9 4.9 to 5.7 35.4 to 41.2
Power steering main delivery hose retaining nut 46.6 to 50.9 4.8 to 5.2 34.4 to 37.6
Power steering turning delivery hose retaining nut 24.5 to 29.4 2.5 to 3.0 18.1 to 21.7
Engine and clutch housing mounting screw and nut
M12, grade 7
77.5 to 90.2 7.9 to 9.2 57.1 to 66.5
Engine and clutch housing mounting stud bolt 39.2 to 49.0 4.0 to 5.0 28.9 to 36.2
Clutch pressure plate mounting screws 23.5 to 27.5 2.4 to 2.8 17.5 to 20.3
Release fork setting screws 23.5 to 27.5 2.4 to 2.8 17.5 to 20.3
Clutch housing and mid case mounting nut M12 102.9 to 117.6 10.5 to 12.0 75.9 to 86.8
Clutch housing and mid case mounting screw M12 77.5 to 90.2 7.9 to 9.2 57.1 to 66.5
Clutch housing and mid case mounting stud bolt M12 38.2 to 45.1 3.9 to 4.6 28.2 to 33.3
Mid case and transmission case mounting bolt M12 102.9 to 117.6 10.5 to 12.0 75.9 to 86.8
Mid case and transmission case mounting nut M12 77.5 to 90.2 7.9 to 9.2 57.1 to 66.5
PTO clutch bearing holder mounting bolts M10 77.5 to 90.2 7.9 to 9.2 57.1 to 66.5
Brake plate mounting screw 9.8 to 11.3 1.00 to 1.15 7.2 to 8.3
