2-S28
MX5100, WSM
CLUTCH
Thickness of Seal Ring
1. Measure the thickness of seal rings (1) with an outside
micrometer.
2. If the measurement is less than the allowable limit, replace it.
W10176900
Thickness of seal ring
Factory spec.
2.45 to 2.50 mm
0.096 to 0.098 in.
Allowable limit
2.0 mm
0.079 in.
(1) Seal Ring
