4-S2
MX5100, WSM
REAR AXLE
2. TIGHTENING TORQUES
Tightening torques of screws and nuts on the table below are especially specified.
(For general use screws and nuts : See page G-10, G-11.)
W10127360
Item N·m kgf·m lbf·ft
Rear wheel mounting screw and nut 197 to 226 20 to 23 145 to 166
ROPS mounting screw 166.7 to 196.1 17 to 20 123 to 144
Rear axle case mounting screw M10 48.1 to 55.9 4.9 to 5.7 35.4 to 41.2
Rear axle case mounting nut M10 60.8 to 70.5 6.2 to 7.2 44.9 to 52.1
Rear axle case mounting screw and nut M12 77.5 to 90.2 7.9 to 9.2 57.1 to 66.5
Rear axle case mounting stud bolt 24.5 to 31.4 2.5 to 3.2 18.1 to 23.1
Rear axle lock nut 196 to 245 20 to 25 145 to 181
