6-S5
MX5100, WSM
FRONT AXLE
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts : See page G-10, G-11.)
2WD TYPE
W10127360
4WD TYPE
W10117570
Item N·m kgf·m lbf·ft
Tie-rod clamp screw and nut 39.2 to 49.0 4.0 to 5.0 28.9 to 36.1
Front axle pivot adjusting screw 19.6 to 29.4 2.0 to 3.0 14.5 to 21.7
Front axle pivot lock nut 58.0 to 98.0 6.0 to 10.0 43.4 to 72.3
Power steering hose retaining nut 24.5 to 29.4 2.5 to 3.0 18.1 to 21.7
Cylinder cover 60.8 to 70.6 6.2 to 7.2 44.8 to 52.1
Front wheel mounting nut 124.0 to 147.0 12.6 to 15.0 91.5 to 108.4
Bracket mounting screw and nut 77.5 to 90.1 7.9 to 9.2 57.2 to 66.5
Tie-rod end nut 49.0 to 68.6 5.0 to 7.0 36.2 to 50.6
Front wheel hub slotted nut 78.5 to 117.7 8.0 to 12.0 57.9 to 86.8
Knuckle arm mounting bolt and nut 77.5 to 90.2 7.9 to 9.2 57.2 to 66.5
Front axle pivot lock nut 58.0 to 98.0 6.0 to 10.0 43.4 to 72.3
Power steering hose retaining nut 24.5 to 29.4 2.5 to 3.0 18.1 to 21.7
Cylinder cover 60.8 to 70.6 6.2 to 7.2 44.8 to 52.1
Front wheel mounting nut 166.7 to 196.1 17.0 to 20.0 122.9 to 144.6
Bracket mounting screw and nut 77.5 to 90.1 7.9 to 9.2 57.2 to 66.5
Tie-rod end nut 156.9 to 176.5 16.0 to 18.0 115.7 to 130.2
Bevel gear case mounting screw 166.7 to 196.1 17.0 to 20.0 122.9 to 144.6
Axle flange mounting screw 29.4 to 34.3 3.0 to 3.5 21.7 to 25.3
Tie-rod joint and steering cylinder mounting screw 166.7 to 196.1 17.0 to 20.0 122.9 to 144.6
Differential case cover mounting screw 60.8 to 70.6 6.2 to 7.2 44.8 to 52.1
