Kubota MX5100 - Page 379

8-S5
MX5100, WSM
HYDRAULIC SYSTEM
HYDRAULIC CYLINDER
W1011871
Item Factory Specification Allowable Limit
Hydraulic Cylinder Bore I.D. 90.000 to 90.050 mm
3.54330 to 3.54527 in.
90.150 mm
3.54921 in.
Hydraulic Arm Shaft to Bushing Clearance (Right)
Clearance (Left)
0.125 to 0.230 mm
0.00492 to 0.00906 in.
0.125 to 0.220 mm
0.00492 to 0.00866 in.
0.50 mm
0.0197 in.
0.50 mm
0.0197 in.
Hydraulic Arm Shaft O.D. (Right)
O.D. (Left)
44.920 to 44.950 mm
1.76850 to 1.76968 in.
39.920 to 39.950 mm
1.57165 to 1.57283 in.
–
–
Hydraulic Arm Bushing I.D. (Right)
I.D. (Left)
45.0756 to 45.150 mm
1.77460 to 1.77756 in.
40.075 to 40.140 mm
1.57775 to 1.58031 in.
–
–
