G-35
MX5100, WSM
G GENERAL
■ Valve Seat
1. Set the injection nozzle to a nozzle tester (Code No. 07909-
31361).
2. Raise the fuel pressure, and keep at 12.75 MPa (130 kgf/cm
2
,
1849 psi) for 10 seconds.
3. If any fuel leak is found, replace the nozzle piece.
W1113031
Valve seat tightness Factory spec.
No fuel leak at
12.75 MPa
130 kgf/cm
2
1849 psi
To Next Page
