Setting: Freq.

Sets the frequency of the CED signal. Used as one of the measures to improve transmission per-

formance for international communications.

1. Select the setting.

Display Description

2100 2100Hz

1100 1100Hz

* : Initial setting: 2100

2. Press the start key. The setting is set.

Completion

Press the stop key. The screen for selecting a maintenance item No. is displayed.
