2NM/2NX/2NY/2NZ/2P0/2P6-1
1-2-4
*: Be sure to hold the both side of the lower
part of the machine by two persons when
carrying it, as shown in the figure.
*: Don't have the operation panel part,
because there is fear of breakage.
Figure 1-2-3
*: Removed the packing components that a fixed tape and shock absorbing material etc. are.
1. A main unit is carried on a paper feeder.
*: Refer to the installation guide for the
details of attachment.
Figure 1-2-4
Precaution for carrying the machine
Remove the tapes and spacer
Install the paper feeder (option)
Paper feeder
Main unit
To Next Page
