Kyocera ECOSYS M3040dn

2NM/2NX/2NY/2NZ/2P0/2P6-1
1-2-3
Figure 1-2-2
*: Place the machine on a level surface.
Unpacking
11
13
12
1
1
1
1
16
18
10
14
7
8
5
4
2
6
9
15
3
17
1. Hinge joints
2. Outer case
3. Upper front pad
4. Upper left pad
5. Upper right pad
6. Waste toner box
7. Power code
8. Operation guide etc.
9. Plastic bag
10. Document tray
11. Main unit
12. Inner pad
13. Plastic bag
14. Plastic bag
15. Lower left pad
16. Lower right pad
17. Lower front pad
18. Bottom case
