Kyocera ECOSYS M3040dn

2NM/2NX/2NY/2NZ/2P0/2P6
1-4-19
(7) Electrical parts that could cause paper jam at the transfer , the fuser and the eject
parts
Timing of detection
Corrective Action
Jam code
J4201,J4211
Related parts
Eject sensor (ES) Control PWB (CONPWB)
Registration clutch (RCL) Connect right PWB (C-RPWB)
Main motor (MM)
Connect left PWB (C-LPWB)
Eject motor (EM)
Checking
procedure at the
occurrence of
J4201/J4211
Corrective action at the occurrence
On/Off control signal output connector
(terminal), point of checking connection
1 Items for Initial Checks See page 1-4-9
2
Eject sensor (ES) : Conduct connectivity
check, mounting location check,
operation check
CONPWB YC26-1
3
Control PWB : Replace
4
Registration clutch (RCL)
: Operation
check (U032)
C-RPWB YC12-6
5
Main motor : Operation check C-RPWB YC10-1/2/3/4
6
Connect right PWB : Replace
7
Eject motor : Operation check C-LPWB YC12-1/2/3/4
8
Connect left PWB : Replace
