2NM/2NX/2NY/2NZ/2P0/2P6
1-3-24
U034 Adj Paper Timing
Description
Adjusts the leading edge registration or center line.
Purpose
Make the adjustment if there is a regular error between the leading edges of the copy image and
original.
Make the adjustment if there is a regular error between the center lines of the copy image and
original.
Method
1. Press the start key.
2. Select the item to be adjusted.
Display Description
LSU Out Top Leading edge registration adjustment
LSU Out Left Center line adjustment
Adjustment: LSU Out Top
1. Press the system menu key.
2. Press the start key to output a test pattern.
3. Press the system menu key.
4. Select the item to be adjusted.
[LSU Out Top]
Display Description
Setting
range
Initial
setting
Change in
value per step
Top The standard value of leading edge 0 to 1180 590 1 dot
MPT Paper feed from MP tray. -70 to 70 -3 1 dot
Cass Paper feed from cassette. -70 to 70 0 1 dot
Dup Duplex mode. (second) -70 to 70 2 1 dot
