2NM/2NX/2NY/2NZ/2P0/2P6
1-2-9
Figure 1-2-12
1. Pull the cassette from the main unit out.
Figure 1-2-13
*: Push the bottom plate down.
(40 ppm model only)
Figure 1-2-14
2. Push the lock lever on the right side
guide and slide to the desired paper
size.
Figure 1-2-15
Loading paper
Cassette
Main unit
Botom plate
Cassette
Lock lever
Paper width guides
