Kyocera ECOSYS M3040dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
1-4-17
*2: 50/60 ppm model only
(5) Paper jam at feeding from multi paper feed
Electrical parts that could cause paper jam during paper travelling at the primary
feeding ( to regist roller)
Timing of detection
Corrective Action
5
Paper feed clutch (PFCL): Operation
check
C-RPWB YC12-4
6
Main motor : Operation check C-RPWB YC10-1/2/3/4
7
Connect right PWB : Replace
Jam code
J0509,J0519
Related parts
Registration sensor (RS) Control PWB (CONPWB)
MP solenoid (MPSOL)
Connect right PWB (C-RPWB)
Main motor (MM)
Checking
procedure at the
occurrence of
J0509/J0519
Corrective action at the occurrence
On/Off control signal output connector
(terminal), point of checking connection
1 Items for Initial Checks See page 1-4-9
2
Registration sensor (RS): Conduct
connectivity check, mounting location
check, operation check
CONPWB YC19-12
3
MP solenoid (MPSOL): Operation check C-RPWB YC11-2
4
Main motor : Operation check C-RPWB YC10-1/2/3/4
5
Control PWB : Replace
Checking
procedure at the
occurrence of
J4002/J4012
J4102/J4112 *2
Corrective action at the occurrence
On/Off control signal output connector
(terminal), point of checking connection
