Kyocera ECOSYS M3040dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6-1
2-3-1
2-3 Appendixes
2-3-1 Appendixes
(1) List of maintenance parts
Maintenance part name
Part No.
Alternative
part No.
Name used in service manual Name used in parts list
Paper feed pulley
Pickup pulley
PULLEY FEED ASSY
PARTS PULLEY PICKUP ASSY SP
(PARTS HOLDER FEED ASSY SP)
302F906230
-
(302LV94270)
2F906230
-
(2LV94270)
Separation pulley RETARD ROLLER ASSY
(CT-3100)
302F909171
(302MS93011)
2F909171
(2MS93011)
Contact glass
Slit glass
CONTACT GLASS
CONTACT GLASS DP
(PARTS FRAME ISU TOP ASSY SP)
-
-
(302NM94030)
-
-
(2NM94030)
CCD
LED
P.W.BOARD ASSY CCD
P.W.BOARD ASSY LED
(PARTS ISU ASSY SP)
-
-
(302NM93010)
-
-
(2NM93010)
MP paper feed roller ROLLER M/P ASSY 302HS08260 2HS08260
MP separation pad PAD SEPARATION MPF - -
Upper ragistration roller PARTS ROLLER REGIST UP SP 302LV94180 2LV94180
Lower ragistration roller PARTS ROLLER REGIST LOW SP 302LV94170 2LV94170
Transfer roller PARTS ROLLER TRANSFER SP 302LV94130 2LV94130
Paper chute guide PARTS GUIDE PAPER CHUTE SP 302LV94261 2LV94261
DU conveying roller ROLLER DU ASSY - -
DU conveying pulley PULLEY PA - -
Upper eject roller ROLLER FD UP - -
Upper eject pulley PULLEY EXIT - -
Lower eject roller ROLLER FD UP - -
Lower eject pulley PULLEY EXIT FUSER - -
DP pickup pulley
DP paper feed roller
DP separation pad
PULLEY PICKUP ASSY
PULLEY PAPER FEED ASSY
PAD SEPARATION
(PARTS DP UNIT SP)
-
-
-
(302NZ94060)
-
-
-
(2NZ94060)
