Kyocera ECOSYS M3040dn

2NM/2NX/2NY/2NZ/2P0/2P6
2-2-4
(3) Connector lists
Connector Pin Signal I/O Voltage Description
YC2
1 EECLK I 0/3.3 V DC(pulse) Clock signal
Connected to
the connect-
left PWB
2 GND - - Ground
3 EESIO I/O 0/3.3 V DC Data signal
4 ERASER I 0/3.3 V DC CL control signal
5 +3.3V2_E2 I 3.3 V DC 3.3 V DC power input
6 TSENS O Analog TS output signal
7 SBMDIR I 0/5 V DC SBM: On/Off
8 WTSENS O Analog WTS output signal
9 SBMENBLN I 0/3.3 V DC SBM output control signal
10 WTLED I 0/3.3 V DC Waste toner LED control
11 SBMSTEP I 0/3.3 V DC SBM step signal
12 MPFSENS O 0/3.3 V DC MPS: On/Off
13 SBMMODE I 0/3.3 V DC SBM mode control signal
14 +3.3V1_E1 I 3.3 V DC 3.3 V DC power input
15 TMOT I 0/3.3 V DC TM: On/Off
16 LFANN I 0/24 V DC LFM: On/Off
17 *1 FUDR I 0/24 V DC FUSOL: On/Off
18 *1 ENVMOT I 0/5 V DC ENVM: On/Off
19 *1 FDDR I 0/24 V DC FUSOL: On/Off
20 *1 DUJAMSEN1
N
O 0/3.3 V DC DUS1: On/Off
21 *1 REGSEN2 O 0/3.3 V DC RS2: On/ Off
22 *1 REARSWN O 0/3.3 V DC RECSW: On/Off
YC3
1 +24V0_E3 I 24 V DC 24 V DC power input
Connected to
the connect-
left PWB
2 GND - - Ground
3 GND - - Ground
4 +24V2_E2 I 24 V DC 24 V DC power input
YC12
1 +3.3V2_E2 O 3.3 V DC 3.3 V DC power output
Connected to
the paper
feed sesor
2 GND - - Ground
3 PAPFULN I 0/3.3 V DC FS: On/Off
YC14 *1
1 +3.3V2_E2 O 3.3 V DC 3.3 V DC power output
Connected to
the lift sensor
2 GND - - Ground
3 LSENS I 0/3.3 V DC LS: On/Off
