Kyocera ECOSYS M3040dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
2-2-5
YC15
1 +24V2_E2 O 24 V DC 24 V DC power output
Connected to
the poligon
motor
2 GND - - Ground
3 PLGDRN O 0/5 V DC PM: On/Off
4 PLGRDYN I 0/3.3 V DC PM ready signal
5 POLCLK O 0/3.3 V DC(pulse) PM clock signal
YC16
1 +5V2_E1 O 5 V DC 5 V DC power output
Connected to
the APC
PWB
2 VDATA1P O LVDS Video data 1 signal (+)
3 VDATA1N O LVDS Video data 1 signal (-)
4 VDATA2P O LVDS Video data 2 signal (+)
5 VDATA2N O LVDS Video data 2 signal (-)
6 SAMPLEN1 O 0/3.3 V DC Sample / hold signal 1
7 SAMPLEN2 O 0/3.3 V DC Sample / hold signal 2
8 OUTPEN O 0/3.3 V DC Laser enable
9 VCONT1 O Analog LD-1 Light volume adjustment
10 VCONT2 O Analog LD-2 Light volume adjustment
11 GND - - Ground
12 PDN I 0/3.3 V DC (pulse) Main scanning synchronizing signal
13 +3.3V2_E2 O 3.3 V DC 3.3 V DC power output
YC19
1 ENVSENSN I 0/3.3 V DC ENVS: On/Off
Connected to
the high volt-
age PWB
2 GND - - Ground
3 MISENS I Analog MC output signal
4 MHVCLK O 0/3.3 V DC (pulse) MC clock signal
5 MACCNT O Analog MC AC control signal
6 MDCCNT O Analog MC DC control signal
7 HVCLK O 0/3.3 V DC (pulse) DEV clock signal
8 BDCNT O Analog DEV DC control signal
9 BACNT O Analog DEV AC control signal
10 PAPERSEN2
N
I 0/3.3 V DC EFS2: On/Off
11 PAPERSEN1
N
I 0/3.3 V DC EFS1: On/Off
12 REGSENSN I 0/3.3 V DC RS: On/Off
13 DUJAMSEN2
N
I 0/3.3 V DC DUS: On/Off
14 +3.3V2_E2 O 3.3 V DC 3.3 V DC power output
Connector Pin Signal I/O Voltage Description

Kyocera ECOSYS M3040dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Max Paper Size	A4
Scan Resolution	600 x 600 dpi
Output Capacity	250 sheets
Copy Resolution	600 x 600 dpi
Maximum Copy Size	A4
Operating Systems	Windows, Mac OS, Linux
Functions	Print, Copy, Scan
Print Speed	40 ppm
Scan Speed	40 ipm
Connectivity	USB 2.0, Ethernet
Warm-up Time	15 seconds
Memory	512 MB
Paper Size	A4, A5, A6, B5, Letter, Legal
Paper Weight	60-220 g/m²
Copy Speed	40 cpm
Scan Type	Color and Monochrome
