2NM/2NX/2NY/2NZ/2P0/2P6-1
1-3-109
Altitude adjust-
ment
Setting altitude adjustment
Description
Sets the altitude adjustment mode.
Purpose
Used when print quality deteriorates in an installation at the altitude of 1,500 meters or
higher.
Method
1. Enter the Service Setting menu.
2. Select [Altitude Adj.].
3. Press the OK key.
4. Select [Normal], [High 1] or [High 2].
5. Press the OK key. The setting is set.
Completion
Press the stop key.
MC Setting main charger output
Description
Sets the main charger output.
Execution is possible only when the altitude adjustment mode is set to [Normal].
Purpose
Execute when the image density declines, dirt of a background or an offset has
occurred.
Method
1. Enter the Service Setting menu.
2. Select [MC].
3. Press the OK key.
4. Select [1] to [5].
5. Press the OK key. The setting is set.
Completion
Press the stop key.
Service items Description
