2NM/2NX/2NY/2NZ/2P0/2P6
1-5-6
2. Remove the spring.
3. Remove the retard roller holder by
rotating.
4. Check or replace the retard roller and
refit all the removed parts.
Figure 1-5-8
Retard roller guide
Spring
Retard roller holder
