Kyocera ECOSYS M3040dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
2-2-11
*1: 50/60 ppm model only
*2: Basic model only
*3: HyPAS model only
YC2002 *2
1 GND - - Ground
Connected to
the opera-
tion panel
PWB
2- -- Not used
3INT_POWER
KEY_N
I 0/3.3 V DC Power key: On/Off
4 FPRST O 0/3.3 V DC Panel reset signal
5 AUDIO O Analog Voice output signal
6- -- Not used
7 PAN_TXD O 0/3.3 V DC Serial comunication data signal
8 PAN_RXD I 0/3.3 V DC Serial comunication data signal
9- -- Not used
10 - - - Not used
11 5.0V2_C O 5 V DC 5 V DC power output
12 - - - Not used
13 LCDCON O 0/3.3 V DC LCD control signal
14 3.3V1_C O 0/3.3 V DC 3.3 V DC power output
15 GND - - Ground
YC2003 *3
1 +5V0 PANEL O 5 V DC 5 V DC power output
Connected to
the opera-
tion panel
PWB
2 +5V0 PANEL O 5 V DC 5 V DC power output
3 GND - - Ground
4 GND - - Ground
Connector Pin Signal I/O Voltage Description

Kyocera ECOSYS M3040dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Max Paper Size	A4
Scan Resolution	600 x 600 dpi
Output Capacity	250 sheets
Copy Resolution	600 x 600 dpi
Maximum Copy Size	A4
Operating Systems	Windows, Mac OS, Linux
Functions	Print, Copy, Scan
Print Speed	40 ppm
Scan Speed	40 ipm
Connectivity	USB 2.0, Ethernet
Warm-up Time	15 seconds
Memory	512 MB
Paper Size	A4, A5, A6, B5, Letter, Legal
Paper Weight	60-220 g/m²
Copy Speed	40 cpm
Scan Type	Color and Monochrome
