Kyocera ECOSYS M3040dn

2NM/2NX/2NY/2NZ/2P0/2P6
2-2-50
11. Pull out the cassette.
12. Remove three screws.
13. Release two hooks by sliding the right
lower cover upward and then remove
the right lower cover.
Figure 2-2-62
14. Remove eight screws and grounding
terminal.
15. Remove the controller box.
Figure 2-2-63
Right lower cover
Screw
Screw
Screw
Hooks
Screw
Screw
Screw
Screw
Screw
Screw
Screws
Controller box
Grounding
terminal
