Kyocera ECOSYS M3040dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
1-2-19
7. Insert the SSD in an option slot.
8. Fix the SSD with using two screws to
main unit.
Figure 1-2-34
9. Refit two interface covers.
10. Close the rear cover.
Figure 1-2-35
11. Connect the plug of the power cord to a
wall outlet.
12. Turn the power switch on.
Figure 1-2-36
Screws
SSD
Option slot
Rear cover
Lower interface cover
Upper interface cover
ON
Power switch
Power cord
Wall outlet

Kyocera ECOSYS M3040dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Max Paper Size	A4
Scan Resolution	600 x 600 dpi
Output Capacity	250 sheets
Copy Resolution	600 x 600 dpi
Maximum Copy Size	A4
Operating Systems	Windows, Mac OS, Linux
Functions	Print, Copy, Scan
Print Speed	40 ppm
Scan Speed	40 ipm
Connectivity	USB 2.0, Ethernet
Warm-up Time	15 seconds
Memory	512 MB
Paper Size	A4, A5, A6, B5, Letter, Legal
Paper Weight	60-220 g/m²
Copy Speed	40 cpm
Scan Type	Color and Monochrome
