04E3920 User Manual QuickTOC
®
purity
ATEX 2 149
8 Care and Maintenance
8.3 Care and Maintenance Tasks
LAR | PROCESS ANALYSERS AG
8.3.18 Replace Reactor Seal
Disassembly:
1. Switch off the oven via the "Service Actions" display (Chapter 7.2.12 on page 106) and allow it to
cool down for 2 hours.
2. Disassemble the ventilation grille on the bottom of the analyser by carefully pulling it forward with
your hands.
3. Loosen the maintenance flap screws on the bottom of the analyser and remove the service cover.
4. Loosen the screws of the second floor grate behind and take it off. Now the reactor foot is visible.
5. Unscrew the four black spacers.
6. Unscrew the three screws from the socket of the reactor base.
7. Loosen the screwed connection with Teflon hose from the reactor foot receptacle.
8. Remove the reactor foot carefully from the reactor pipe.
Notice
The reactor tube filling shown in Abb. 104, Seite 147 is an excellent solution for the
majority of applications.
However, some applications can be optimized by varying the listed default fill. Any de-
viations from the standard filling should be discussed in advance with LAR Technical
Support or with a LAR authorized service partner.
As our research and development progresses, we ask that you stay in touch with your
LAR contact to stay up-to-date with any additions
Danger
Danger of burns
Allow the furnace to cool completely (2 hours in total). One hour after switching off the
furnace, the temperature of the reactor tube is still about 400° C to 500° C!
Always use heat-resistant gloves when working on the furnace.
Warning
Correct installation of removed components
During assembly, remember that all parts that have been removed and / or disassem-
bled must be reassembled as they were in their original condition.
