11 Technical Data
11.1 Specifications
11 Technical Data
11.1 Specifications
Notice
All graphic, electronic or mechanical changes intended for technical progress are re-
served.
Tabelle 19: Analyser specifications
Type Dimensions/Description
Housing Explosion protected housing, stainless steel (IP65),
Certification ATEX EX II 3G Ex pz II T3 or EX II 3G Ex pz II T4
Type of explosion protection Overpressure encapsulation with rinse
Dimensions of the analyser
(W x H x D)
T3 Configuration: 920 x 1.060 x 635 mm (W x H x D)
T4 Configuration-Konfiguration: 1.010 x 1.060 x 635 mm (W x
H x D)
Housing volume 1 Channel 300 l
6 Channels 360 l
Weight from approx.. 160 kg (depending on the configuration)
Mains voltage
(see specifications on the type pla-
te)
115/230 V/AC at 50/60Hz
Fusing minimum 16A (K-characteristics)
Power input approx. 1,2 KW
Signal outputs Number: depending on configuration 2 - 33 analog outputs
Warning: Each analog output is galvanically isolated from
the other analog outputs and the analog outputs are
galvanically isolated from the housing.
0 – 20mA or 4 – 20mA
max. load 500 Ohm
Interface serial interface RS 232
Noise level max. 70 dB
Potential-free contacts 8 programmable relays (NO or NC)
Voltage: max. 24 V=, 24V~
Amperage: max. 1 A=, 1A~
USB interface USB 2,0
Display 10,4“ resistive Touchscreen, TFT Display
Carrier gas consumption Standard: approx. 30 l/h (Nitrogen 5.0)
External air supply(optional) Dew point max. -5°C
Digital inputs 8 digital inputs
