5 Start-up
5.1 Procedure
5 Start-up
This section provides all information about the start-up of the analyser. The following start-up procedure
serves as an overview. The start-up must be carried out properly and documented by Technical Support
of LAR or by another person authorised by LAR.
5.1 Procedure
The start-up procedure is divided into start-up of the analyser and start-up of accessories.
5.1.1 Start-Up of the Analyser
1. Checking the Pre-fusing (Chapter 5.2 on page 62)
2. Checking the mounting plate (Chapter 5.3 on page 62)
3. Removing the transportation locks (Chapter 5.4 on page 63)
4. Aligning the voltage (Chapter 5.5 on page 65)
5. Switching on the fuses (Chapter 5.6 on page 65)
6. Filling and installing the reactor pipe (Chapter 5.7 on page 65)
7. Completing the furnace system (Chapter 5.8 on page 68)
8. Installing the pump tubes (Chapter 5.9 on page 70)
9. Tubing the analyser (Chapter 5.10 on page 72)
10. Connecting the control unit and the relays (Chapter 5.11 on page 73)
11. Connecting the furnace emergency cooling (Chapter 5.12 on page 74)
12. Switching on the analyser (Chapter 5.13 from page 74)
13. Setting the bypass for the control unit (Chapter 5.14 on page 75) and switching into bypass mode
14. Rinsing the injection system and the sample tubes (Chapter 5.15 on page 76)
15. Customizing application-specific settings (Chapter 5.16 on page 76)
16. Checking status parameters (Chapter 5.17 on page 76)
17. Performing a calibration (Chapter 5.18 on page 76), if need be, performing a second calibration.
Tabelle 6: Start-up protocoll for the analyser
Warning
Warning of improper start-up
Do not switch on the analyser before start-up without having completed the installation
(described in the previous chapter) and without the presence of a technician authori-
sed by LAR - because this voids the warranty of your analyser.
Task Criteria OK Comment
Checking the Pre-fusing • Pre-Fuse is installed correctly

Checking the Mounting
plate
• Components are fixed

Removing the transportation
locks
• Furnace Transport Screw is
removed

Aligning the voltage • Voltage is correct

Date: Signature:
!
