5.10 Analyser Tubing LAR | PROCESS ANALYSERS AG
5.10 Analyser Tubing
Inside the analyser, samples, reagents and the carrier gas are transported from one component to the
next. Different tubes are used for this, which must be connected properly to the components.
Ensure for tubing that
• tubes are in perfect condition (e.g. no kinks)
• routing diagram is observed depending on configuration
• tubes are hand-screwed onto the screwed joints
• drain is depressurisedf
Notice
For tubing of your analyser, follow the flow diagram for your configuration (Chapter 12
from page 217).
