4 Installation
4.2 Site Selection - Ambient Conditions LAR | PROCESS ANALYSERS AG
Tabelle 5: Installation protocol for the analyser
4.2 Site Selection - Ambient Conditions
The following ambient conditions apply for choosing the analyser location:
• Dry and frost-proof
• Allowed temperature ranget 5°C - 35°C
• Max. relative humidity 80%
• No direct exposure to sunlight
• No aggressive environment for housing type IP54
• Mains voltage 115/230 V at 50/60 Hz, 16 A fusing (K-characteristics)
Task Criteria OK Comment
Ensure Environment
Conditions
• Dry and frost-proof
• Temperature: 5 -35° C
• Rel. humidity: < 80%
• No direct exposure to sunlight
• No aggressive environment
• No aggressive sample contents

Mounting and Installa-
tion of the Analyser on
Site
• Wall mounting:
Free space (W x H x D)
approx. 1.430 x 1.760 x 1.190 mm

• Mounting rack:
Free space (W x H x D)
approx. 1.500 x 2.000 x 1.420 mm

Provide Carrrier Gas
• Free of CO
2
, Carbon, Dust,
Water und Oil
• Pre pressure 3,5 - 4 bar
• Available in the direct vicinity

Provide Sample Inlet
• Depressurised
• Available in the direct vicinity

Provide Drain
• Depressurised
• Available in the direct vicinity

Provide Power Supply
• Mains voltage correct
• Power cable on power supply
connected

Install Signal
Connections
• Serial interface connected
• Digital Inputs connected
• Analog Outputs connected
• Relays connected

Provide Rinsing Water • Rinsing water provided

Provide Acid Solution • Acid solution provided

Provide Calibration
Standards
• Calibration Standard provided

Date: Signature:
