4.3.1 Maximum Swing-Open of the Analyser
Fig. 33: Maximum swing-open of the analyser
Notice
For all mounting options, distance to side and opposite walls must be maintained so
that the analyser can be swung open.
i
1
2
3
1 Rear housing
2 Front housing
3 Housing door
