3.6 Components of the Explosion Protection LAR | PROCESS ANALYSERS AG
3.6.3.2 Power Supply
Fig. 25: Connection to power supply
Warning
Warning of improper electrical connection
The analyser may be damaged if it is connected to a local power supply not specified
on the type plate.
Before switching on the analyser, check that the local voltage supply matches that on
the rating plate.
If this power supply is not available, contact LAR Technical Support.
Do not switch on the analyser without a LAR-authorized technician before using it for
the first time, as this will void the warranty of your analyser!
Warning
Warning about improper commissioning
The analyser may be damaged if improperly put into operation.
Do not switch on the analyser without a LAR-authorized technician before using it for
the first time, as this will void the warranty of your analyser!
PE (green): Protective conductor
N (blue): Neutral
L (gray): Conductor
!
!
