3 Product
3.6 Components of the Explosion Protection
LAR | PROCESS ANALYSERS AG
gas.
Only after successful rinsing is the analyser (3) switched on and the interfaces connected to the custo-
mer level.
An error is output at a relay output of the control unit as "Alarm".
For service work on the device by trained personnel there is a bypass mode in the control unit, which is
protected by a password
Fig. 18: Components of the Overpressure System
2
3
1
