DIGISONDE-4D
SYSTEM MANUAL
VERSION 1.2.11
SECTION 5 - SYSTEM SOFTWARE – ANNEX B 5-55
ANNEX B
DCART TO DESC INTEFACE CONTROL DOCUMENT
COMMAND PACKETS
5:119. DCART send these packets to DESC.
Periodic Message packet TYPE=0x70, Length = 17.
5:120. The packet is used to set time on the DESC computer.
Table 5B- 1: Periodic Message packet TYPE=0x70, Length = 17
Byte
Offset
Byte
Len
Mnemonic
Description
Units
Type
Range
0
Time
LEN
TS
Time Stamp (see Table 5A- 13)
-
Switch to Standby state packet TYPE=0x81, Length = 0.
5:121. The packet is used to set DESC in Standby state.
Switch to Diagnostic state packet TYPE=0x82, Length = 0.
5:122. The packet is used to set DESC in Diagnostic state.
Switch to Scheduled Operations state packet TYPE=0x84, Length = 0.
5:123. The packet is used to set DESC in Scheduled Operations state.
Load program packet TYPE=0x71, Length = LEN.
5:124. The packet is used by DCART to upload program to DESC that uses it to fill the appropriate program
definition structure (see Table 5A- 6 to Table 5A- 9)
Table 5B- 2: Load program packet TYPE=0x71, Length = LEN
Byte
Offset
Byte
Len
Mnemonic
Description
Units
Type
Range
0
1
PRN
Program Number
-
INT8U
1..255
1
LEN
PR
Operation (Table 5A- 6 to Table 5A- 9)
PR struct
