LDI Intellectual Property.
Not for secondary distribution or replication, in part or entirety.
DIGISONDE-4D
SYSTEM MANUAL
VERSION 1.2.11
SECTION 3 - OPERATING INSTRUCTIONS 3-15
Programming Vertical Incidence Ionogram Measurement
3:25. The following data processing options shall be considered when programming the ionogram measure-
ment:
a. OUTPUT FILES: RSF versus SBF output format.
Default setting is RSF (Routine Scientific Format), ionogram with echo directions
SBF (Single Byte Format), for ionograms without echo directions, used for sustaining operations
during periods of hardware faults in one or more receiver channels
b. TWO-FREQUENCY PRECISION RANGING / PRECISION GROUP HEIGHT (PGH)
Precision ranging is disabled by default.
Precision ranging is enabled by (a) setting number of fine steps to 2 and (b) selecting fine frequen-
cy step of 5 kHz. Then data from the second frequency are used to calculated precise range of ech-
oes with 1 km resolution and then discarded.
NOTE
Ionograms with enabled two-frequency precision ranging take double time to complete.
Precision ranging mode requires RSF format for the output ionograms
c. DATA REDUCTION: enabled/disabled
Data reduction is disabled by default.
For locations with a limited Internet bandwidth available for data delivery to the external data re-
positories, it may help to threshold data below the noise level (as determined by most probable am-
plitude, MPA) for a better file compression.
d. RFIM:
RF Interference Mitigation removes powerful narrowband interferers in the receiver bandwidth
RSF Ionogram with Echo Directions
3:26. Typical example of the RSF ionogram measurement program and corresponding ionogram display is
shown in Figure 3-8. The concept for assigning colors to echo directions is explained in Section 1, Chapter 1.
The insert in Figure 3-8 summarizes the mapping and provides direction codes used in the color legend. “No
Value” color is used for signals whose direction of arrival could not be determined reliably.
