SECTION 6 - MAINTENANCE 6-15
Table 6-4: Maintenance Spares Recommendation
#
Item
Part
Placement
QTY
1
AS-5021107 Rev D
DPS4D Tracker Card
Card File slots 1,2,3,4
1
2
AS-5021105 Rev B
DPS4D Receiver Card
Card File slot 5
1
3
AS-5021104 Rev C
DPS4D Transmitter Card
Card File slot 6
1
4
AS-5021301 Rev B
DPS4D Pre-Processor Card
Card File slots 7,8
1
5
AS-5021108 Rev B
DPS4D BIT Card
Card File slot 9
1
6
AS-5021202 Rev H
DPS4D Power Dist Card
Processor Chassis
1
7
AS-7020103 Rev C
DPS4D Ant. Switch Assbly
Processor Chassis
1
8
HS-872PEDG2
DPS4D Control Computer
Processor Chassis
1
8a
PCE-4129G2-00A1E
DPS4D Data Computer
Processor Chassis
1
8b
1960053207N001
DPS4D Data Computer CPU Fan
Processor Chassis
1
8c
PCE-3B03A-00A1E-LDI
DPS4D Data Computer Backplane
modified by LDI w/ volt. regulators
Processor Chassis
8d
PCE-1G-01
DPS4D Data Computer Network
Card
Processor Chassis
9
MZ-75E500B/AM
DPS4D SSD for Data Platform
Processor Chassis
1
10
Gain Resistor Set
Resistor Set
Receive antenna boxes
1
11
AS-7040010 Rev J
DPS4D Preamp/Polariz. Box
Receive antenna
1
12
3610KL-05W-B50
Fan Axial, 92 mm
DPS4D Enclosure
1
13
AFB0624HH
Fan Axial, 60 mm
DPS4D Enclosure
2
14
09362-F/45
Filter, Air, 92 mm
DPS4D Enclosure
3
15
8 Amp Fuse
8 Amp Fuse
RF Amplifier Chassis
2
