Viva Series, Roads - Road 1314
45.2.4 Toggle Offsets Right/Left
Description If staking out a street that is defined as a centreline with offsets of 2.5 m left and right, this
functionality allows to toggle between the two lines to stake out.
This functionality is available for the following stake out/check methods:
a) Centreline
b) Defined Stake offset
c) Parallel right stringline
d) Parallel left stringline
Type Description
Stringline Toggle between parallel stringline left and right.
Cross slope Toggle between left and right stringline of the cross slope.
Crown Toggle between left and right cross slope.
a
b
b
d
c
Road_073
