Viva Series, Instrument connections - CS connection wizard 319
16.3 Connection Using Cable
CS Connection Wizard -
Connect the cable
between the total station
& CS. Ensure same
settings are made on the
CS.
Description of fields
Key Description
Next To confirm the settings and to continue to the next screen.
Default To return the fields back to their default values.
Back To return to the previous screen.
Fn Quit To exit the screen.
Field Option Description
Baud rate From 1200 to
115200
Frequency of data transfer from instrument to device
in bits per second.
