Viva Series, User - Check & Adjust 628
30.4 Combined Adjustment (l, t, i, c and ATR)
Access In Check & Adjust Wizard, What do you want to do? select Check & adjust the compen-
sator, index error, line of sight error & automatic target aiming and press Next.
Description The combined adjustment procedure determines the following instrument errors in one
process:
)
Before determining the instrument errors, the instrument has to be:
• levelled up using the electronic level
• protected from direct sunlight
• acclimatised to the ambient temperature, approximately 2 minutes per °C difference
compared to the storage place.
Check & Adjust Wizard,
Step 1
l, t Compensator longitudinal and transversal index errors
i Vertical index error, related to the standing axis
c Horizontal collimation error, also called line of sight error
ATR Hz ATR zero point error for horizontal angle - option
ATR V ATR zero point error for vertical angle - option
Key Description
Next To measure the target.
Fn Quit To exit the wizard.
