Viva Series, TPS Functions 684
33.2.2 PowerSearch
Description The PowerSearch module allows an automatic prism detection within a short time period.
The PowerSearch function can be started in the Leica TPS Favourites screen and configured
in TPS settings\Prism search settings, PowerSearch window.
Functionality
The PowerSearch function consists of a
transmitter (a) and a receiver (b). Both are
installed in the telescope.
When PowerSearch is activated, the instru-
ment starts to rotate around its standing
axis. The transmitter emits a vertical laser
swath. If the laser swath detects a prism, the
rotation of the instrument is stopped. After-
wards an automatic aiming measurement in
the vertical direction is performed.
a) EGL
b) Transmitter
c) Receiver
