Viva Series, Jobs & Data - Import data 192
9.4 Importing Data in DXF Format
Requirements At least one file in DXF format with the file extension *.dxf has to be stored in the \DATA
directory of the data storage device.
)
Do not remove the data storage device while importing the data.
Access Select Main Menu: Jobs & Data\Import data\Import DXF Data.
Import DXF Data
Key Description
OK To import the data.
Config.. To define the format of the data to be imported.
Fn Quit To exit the screen.
To Next Page
