Viva Series, Determine Coordinate System 930
39.4.2 Computing Required Azimuth
Description Available for:
• One Point Localisation method with Onestep or Twostep transformation.
• Method: Two WGS84 points and Method: User entered in Determine Rotation.
Allows two local points to be chosen from local job between which the required azimuth will
be computed. This azimuth is then used with an azimuth computed between two WGS 1984
points chosen from the WGS84 job to calculate the rotation of the transformation.
The computed required azimuth appears in the Required azimuth field for Method: Two
WGS84 points and the Rotation field for Method: User entered in Determine Rotation.
Access Press Inv in Determine Rotation.
Compute Required
Azimuth
Key Description
OK To calculate the required azimuth and return to the screen from where
this screen was accessed.
