Viva Series, Instrument connections - TPS connection wizard 310
15.5 Connection To Leica Legacy and Third Party Total Stations
)
Once you begin working with the CS always work on the controller! Do not touch the total
station software, excluding turning the laser pointer, laser plummet or guide lights on/off
for some models.
)
Refer to "33.7 Connection to Other Total Stations" for supported functions.
Settings required Before using any Leica Legacy or third party total station, please ensure that the following
values are set on the TPS:
Instrument Settings
Leica Legacy total station 1. Total station ppm/scale:
•Atmospheric ppm=0
• Geometric ppm = 0 or scale factor = 1
These settings ensure that the correct coordinates are calcu-
lated at the CS. It is still possible to apply the relevant atmos-
pheric and geometric ppm/scale factor values. These values
must then be set on the CS.
2. Communication settings:
• The communication settings on the TPS must match the
default parameters for that particular instrument type as
seen on the CS.
• For TPS1000, TPS2000 and TPS1100 instruments ensure
the TPS is in the measurement screen when trying to
connect.
