Viva Series, Antenna Heights 286
13.3 Determining Antenna Heights
13.3.1 Pillar Setup
)
• One of the Leica standard antennas is used, for example GS15. All former Leica antenna
types are supported.
• Leica standard accessories are used.
Pillar setup
a) Mechanical reference plane
b) Vertical phase centre offset for L1
c) Vertical phase centre offset for L2
d) Vertical height reading
Vertical offset = 0
GS_033
d
a
b
c
