Viva Series, Coding 545
25.2.2 Thematical Coding without Codelist
Requirements • Use a list box to view codes is NOT checked in Coding & Linework Settings.
• A survey screen page with an editable field for codes must be configured.
• A survey screen page with a selectable list for code types must be configured.
Access A thematical code is typed in the field
Code in a survey screen page of an application.
OR
Code/Point code in New Point, Code page. The procedure is similar for lines and areas.
OR
Point code in Edit Point:, Code page. The procedure is similar for lines and areas.
OR
in the field Code (auto) in Survey, Auto page, if configured.
Survey,
Code page
Type in a code and attribute values. Up to eight attributes can be added. This setting is
configured in the survey screen page.
• If a point code is selected then any open line/area is closed. The measured point is
stored with the selected code independently of any line/area.
• If a line code is selected then any open line is closed and a new line with the selected
code is created. The line ID is defined by the configured line ID template. The meas-
ured point is assigned to that line. The line stays open until it is closed manually or
another line code is selected.
• If an area code is selected then the behaviour is as for lines.
Next step
Press Meas.
