Viva Series, Instrument - TPS settings 236
11.5 Offsets & Quality Control
Description Quality control
The instrument can be configured to monitor sequentially stored measurements and to
notify the user if the coordinates lie within a defined range of each other.
If configured, the X,Y coordinates of a point being stored can be compared to the coordi-
nates of the last previously stored point. If the difference is less than the defined position
tolerance then a warning is shown. It can now be decided whether to store the point or not.
If configured, backsight target points and resection target points which were measured
during the setup procedure are then also checked in this manner.
Offsets
The offset values are applied to measured points. The Offset function allows offset points
to be determined, for instance when the reflector cannot be set up directly on a point.
Transverse, longitudinal and/or elevation offsets can be defined from the reflector position
to the offset point. All of the displayed and recorded measurement data is in relation to the
offset point.
