Viva Series, Instrument - Instrument status info 489
21.7 Connection status
21.7.1 Connection Status
Description This screen gives an overview of all interfaces with the port and the devices currently
assigned.
Access Standard access from the Instrument status info/Base status info menu.
Connection Status This screen consists of two pages, one for the field controller interfaces and one for the GS
interfaces. For a GS05/GS06/GS08/GS12, the GS connections page is not shown.
Key Description
OK To return to the Main Menu.
Intfce Available for configured interfaces being highlighted. To view information
related to real-time data or the internet connection.
Devce.. To view the status of the attached device.
To Next Page
